Commercial 60 Minutes Metal Steel Emergency Exit Doors Single Swing
Contact Person : lan
Phone Number : 176 3354 0888
| Minimum Order Quantity : | 1 set | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Inside Bubble Bags+ Strong Carton+Wooden Frame | Delivery Time : | 35 Days After Payment Received |
| Payment Terms : | western union, moneygram,cash, l/c, t/t | Supply Ability : | 600 Sets per Day |
| Place of Origin: | CHINA | Brand Name: | ZHONGWO |
|---|---|---|---|
| Certification: | BS， WHI， UL, CCC | Model Number: | ZW-GM02(T) |
|
Detail Information |
|||
| Material: | Galvanized Steel | Fire Rating: | 30 Min |
|---|---|---|---|
| Size: | Customized Size | Infilling: | Fireproof Perlite Board |
| Opening Degree: | 90-120 Degrees | Frame Depth: | 90 Mm |
| Thickness Of Steel Sheet For Door Frame: | 1.2 Mm | Thickness Of Steel Sheet For Door Leaf: | 0.8 Mm |
| Highest Temperature Rise: | 69.3 ℃ | Opening Force: | 50 N |
| Highlight: | half hour fire door,fd30 internal doors |
||
Product Description
Single Swing FD30 Fire Door With Glass For Commercial Buildings/ Powder Coated Finish/Half Hour Fire Door
FD30 Steel Fire Door
All of Zhongwo FD30 steel fire doors are class A fire doors and are certified according to BS476-22:1987. We can provide you with relevant testing report and certificates in order to verify the door’s fire integrity and insulation. Generally our FD30 steel fire doors sets consist of door frame and door leaf. We can also provide individually the door frame or door leaf.
Features:
Eco-friendly& Healthy Infilling Material: All of our fireproof perlite board must reach level A1 of the combustion performance standard according to GB8624-2006 and level ZA2 of toxicity standard according to GB/T20285-2006.
Top Appearance Quality: Surface adopts technology without welding spots, so that to get smooth appearance.
Customized Products: Nearly all of our steel fire doors can be customized as your request.
High Performance of Fire Integrity & Insulation: Average temperature rise on door leaf stays at 63.9℃(Standard: ≦140℃), highest temperature rise on door leaf at 69.3℃(Standard: ≦180℃), on door frame 80.6℃(Standard: ≦360℃).
Perfect Process: Dimensional diveation zwischen theoretic standard and practical process is 0 mm.
Main Points of Installation
Firstly the fire doors must be opened outwards, in the direction of corridors and evacuation passages. There are two kinds of installation type for pipe shaft door, that are installation on ground directly and raised one (with low wall and opening hole on the wall). Excluding floor tile and other factors, measure the size of the wall opening and install the doors. According to whether there are other obstacles on the left and right sides of the door, such as fire hydrant box, elevator door, column and other factors to choose the opening direction of the door, that is, opening left and right .
Accessory
We can provide you different kinds of accessories including fire door closers, fire door holders and fire locks, hinges and handles, latches of top quality. There are many brands from China and International countries for your choice, for example Kinlong, Hardrock and Dorma etc.
| Product Name | FD30 Fire Door |
| Fire Rating | 30 min |
| Weight | 20-25Kg/m2 |
| Material of Door Leaf | Galvanized Steel Sheet |
| Material of Door Frame | Galvanized Steel Sheet |
| Thickness of Steel Sheet of Door Leaf | ≧0.8 mm |
| Thickness of Steel Sheet of Door Frame | ≧1.2 mm |
| Thickness of Door Leaf | 40 mm |
| Frame Depth | 90 mm |
| Opening Degree | 90°-120° |
| Open Style | Swing Open, Left Handed, Right Handed |
| Infilling Material | 30min: 38 mm Fireproof Perlite Board(300±30kg/m3) |
| Surface Treatment |
Powder Coating; Heat Transfer Printing |
| Color |
Heat Transfer Printing:1. Rosewood, 2.Oak Wood,3.Walnut Wood or as Request Powder Coating: Milk White, Matte Orange, Dark Gray, Cold Gray White or as Request |
| Fireproof Seal Strip | FPJ-A-15X 2 |
| Package | Inside Bubble Bags + Strong Carton + Wooden Frame |
| Delivery Time | 35 Days After Payment Received |
| Application |
Cable Well, Tube Wells, Exhaust Well, Garbage Wells |
Colors Options
Packaging&Delivery
1. Matured packaging team consisting of professional and well-trained packaging staff with quality packaging materials.
2. Quick delivery within 35 days since transfer confirmed.
3. Reliable and professional logistics services which are all in long-term cooperation with us.
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
Why Choose Us?
1. All of our fire doors are in top quality and at competitive prices.
2. Free pre-sales consult on any questions about fire doors.
3. Brand Advantage: We insist purchasing to be a reliable fire doors supplier for high-end real estate agents.
4. All fire doors can be customized as your request.
5. Good after-sale service.
